FTTH Optical Fiber 16 Core Splitter Distribution Box with Mini PLC Splitter

Product Model

 SP-1606-16G

Product Description

SP-1606-16G This box is able to hold up to 16 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitter, distribution, storage and cable connection in one solid protection box.

Features

Features:

  1. Water-proof design with IP-55 Protection level.
  2. Integrated with splice cassette andcable management rods.
  3. Manage fiber in a reasonable fiber radius condition.
  4. Easy to maintain and extend the capacity.
  5. Fiber bend radius control more than 40mm
  6. 2 pcs 1*8 or 1 pc 1*16 splitter can be installed as an option.
  7. Efficient cable management.
  8. 16 ports cable entrance for drop cable.
Specification

Specification:

Model SP-1606-16G
Material PC+ABS
Size 220*140*55
PLC 2 pcs 1×8 or 1pc 1×16 steel tube PLC Splitter
Weight 0.6kg
Application

Application:

FTTH
FTTA
CATV
FTTX
