12 Fiber FTTA Multiport Service Enclosures With Toneable SST Drops

Product Description

FiberHub is a new economic fiber distributed solutions for outdoor use. Compare traditional products, FiberHub is easy to operate and has high compatibility. It can be used for wall-mounting, aerial installation or holding pole installationi, based on different situation. FiberHub not only used in FTTH field, but also used in FTTA or other harsh environment field.

Features

Features:

High compatibility: can be assembled ODVA, H connector(OptiTap compatible), Mini SC, ODC, PTLC, PTMPO or power adapter.

Factory-sealed or field assembly.

IP68 water and dust protection

Strong enough: working under 1200N pulling force long term.

From 2 to 12 ports for single or multifiber harsh connectors.

IP68 waterproof rating.

Wall-mounting, aerial installation or holding pole installation.

Decreased angle surface and height make sure no connector interfering when operating.

Meet IEC 61753-1 standard.

Cost effective: save 40% operating time.

Available with PLC or splice sleeve for fiber divide.

Specification

Specifications:

Dimensions(LxWxH)	365x137x90mm(Without cover) 375x142x120mm(With cover)
Ingress Protection	IP67
Working Temperature	-40~85℃
Cable Strength Member	Armoured or Non-armoured
Cable Type	Hybrid or non-hybrid
Round Cable OD	5.0mm to 14.0mm
Flat Cable Dimension	4.6×8.9mm
Cable Jacket Material	LSZH,PE or TPU
Bending Radius	20D
Cable Crush Resistance	200N/cm long term
Tensile Strength	1200N long term
UV Resistance	ISO 4892-3
Fire Protection Rating	UL94-V0
Number of PLC	1~2pcs
Number of Fusion Protection Sleeves	1~24pcs
