Features
- Should ensure simple, high-quality installation and maximum network performance.
- Plug-in and playable connector functionality
- Strong cables that do not require pipe protection
- Insensitive to bending
- External and internal with fire resistance
- Designed to prevent water ingress
- Flexible due to the low bending radius and modular design
Specification
Cable Requirements:
- Optical cable for outdoor use
- Connector polishing type, UPC
- Optical Fiber type: Multimode duplex
- Connector type: LC
- Flammability: IEC 60332-3-24, UL 1666 OFNR
- Water penetration: IEC 60794-1-2 F5B
- UV resistance according to ISO 4892-3
- Jacket material: LSZH-CPR compliance: DCA-s1, d0, a1
Mechanical Properties:
- Torsion resistance 15N (for cable from 2 to 3 mm)
- Static side load 1N to 1 h
- Connection mechanism strength 80N (for cable from 2 to 3 mm)
- Operating temperature range: -25°C to +70 °C
Connection:
- Connector A LC Duplex
- Connector B LC Duplex
Environment:
- Installation Area Indoor and outdoor
- Temperature range, normal operation -40°C to +80 °C
Application
Applications:
- Multi-purpose Outdoor
- For connection between distribution box and RRH
- Deployment in Remote Radio Head cell tower applications
