SC Singlemode Female-Male Fiber Attenuators 5dB

Product Model

SC Male-Female Attenuators

Product Description

SC single mode fiber attenuators are commonly used in fiber optic communications to the the power level of a fiber cable by controlling the amount of signal loss that is passed through the signal. Commonly used attenuation range is from 1dB to 20dB.The most commonly used type is female to male plug type fiber optic attenuator, it has the optical fiber connector at one side and the other side is a female type fiber optic adapter, fiber optic attenuator name is based on the connector type and the attenuation level. SC Build Out Fiber Attenuators include SC/UPC fiber attenuators and SC/APC Female to Male Fiber Attenuators.

Features

Features:

Fiber Optic Communication Systems
Local Area Networks (LAN)
DWDM Equipment

Dimension

Fiber Connector	FC/UPC	Connector Gender	Fixed Female to Female
Transfer Mode	Singlemode	Attenuation	1~25dB
Operating Wavelength(nm)	1260~1650(SM)	Attenuation Accuracy	1~5dB±0.5,6-10dB ±0.7，>10dB±1.0
Return Loss	≥55dB	Max Optical Input Power	200mW
Operating Temp Range	-40~75℃	Polarization Dependent Loss	≤0.2dB
Storage Temp Range	-40~80℃	Humidity	95%RH

Accessory

Spring Optical Communication is one of the largest and best fc singlemode bullhead fiber attenuators manufacturers and suppliers with rich experience. Welcome to buy our high quality products or wholesale our customized fc singlemode bullhead fiber attenuators in stock with our factory. Also, free sample is also available if necessary.
