SC/APC Singlemode Female-Male Fiber Attenuators

Product Model

SC/APC Male-Female Attenuators

Product Description

SC/APC single mode fiber attenuators are commonly used in fiber optic communications to the the power level of a fiber cable by controlling the amount of signal loss that is passed through the signal. Commonly used attenuation range is from 1dB to 20dB.The most commonly used type is female to male plug type fiber optic attenuator, it has the optical fiber connector at one side and the other side is a female type fiber optic adapter, fiber optic attenuator name is based on the connector type and the attenuation level. SC Build Out Fiber Attenuators include SC/UPC fiber attenuators and SC/APC Female to Male Fiber Attenuators.

Features

Features:

Metal ion doped fiber
High-power light source durability
Wavelength independence
Attenuation levels ranging from 1dB to 25dB
1310nm, 1550nm and 1310/1550nm dual wave lengths

Dimension
Attenuation Value 1dB ~ 30dB
Operating Wavelength 1240 ~ 1620nm (Dual 1310/1550nm)
Premium
Return Loss UPC >55dB
APC >65dB
Attenuation
Accuracy
1 ~ 7 dB ±0.5dB
8 ~ 12 dB ±0.7dB
13 ~ 17 dB ±1.0dB
18 ~ 25 dB ±1.3dB
Maximum Optical Input Power 1000mW
Polarization Dependent Loss ≤0.1dB
Operating Temperature Range -40 to 75
Storage Temperature Range -40 to 85
Humidity 95%RH
Accessory

Spring Optical Communication is one of the largest and best fc singlemode bullhead fiber attenuators manufacturers and suppliers with rich experience. Welcome to buy our high quality products or wholesale our customized fc singlemode bullhead fiber attenuators in stock with our factory. Also, free sample is also available if necessary.
